FD-V8L
FD-V8L FD-V8L FD-V8L FD-V8L

FD-V8L

Product code: robot-004

Quick Overview

6 Axis, Payload 8 Kgs

Listed Price
0 THB

Long arm with a maximum payload of 8kg.

The range of welding applications has been expanded.

  • Faster cycle time: Due to the industry‚Äôs fastest speeds,cycle times are reduced.
  • Slim design: Slimmed lower arm and reduced rotating radius. Avoiding the interference with jigs or workpiece.
  • User-friendly operation: All cables required for Synchro-feed welding are also built in the lower arm. Avoiding the interference behind the arm.
  • Stronger structure: The maximum payload has been increased by 30%, up to 8kg. Enabling the use of a variety of torches and sensors. It is also good for handling application.
Specification

Number of Axes

6
Maximum Payload Capacity 8 kg
Maximum Working Range Radius 2,006 mm
Positional Repeatability ± 0,08 mm
Mass (Weight) 280 kg
Driving Capacity 5,000W
Installation Method Floor / Wall / Ceilling
Maximum Speed
Rotation/Lower/Upper Arm Arm J1, J2, J3 [195°/s; 200°/s, 200°/s]
Swing/Bending, Torch Wrist J4, J5 [430°/s]
Twist Wrist J6 [630°/s]
Robot Application Arc Welding, Handling
Axes 6 Axis
Payload (kg) 008-020 kg
Working range (mm) 1500-2071 mm
Weight 273.0000
